Core Product Highlights

Proven Weichai Power Assembly, Strong Power & Low Fuel Consumption

It adopts Weichai WD10G220E21 in-line 6-cylinder 4-stroke engine, rated power 162kW@2400r/min and maximum torque of 920N・m, with minimum fuel consumption ≤215g/kW・h. The power system is matched with a single-stage four-element dual-torque hydraulic torque converter and planetary power gearbox, reaching a maximum driving speed of 38km/h. Abundant torque supports heavy digging work and reduces long-term fuel expenditure.

Powerful Traction & Breakout Force, Excellent Performance on Rough Terrain

SLG653G delivers maximum tractive force of 150KN and maximum breakout force ≥160KN, with a maximum gradeability of 30°, enabling easy excavation of hard soil and aggregates. The minimum ground clearance reaches 480mm to avoid scraping on uneven roads. With 2920mm wheelbase, 2280mm wheel tread and standard 23.5-25 industrial tires, the machine provides stable adhesion and prevents slipping on muddy sites and slopes. Overall dimension: 8700×3000×3400mm, minimum turning radius 6201mm, realizing flexible steering in narrow stockyards.

High-Speed Cycle Hydraulic System with Automatic Bucket Levelling

The hydraulic system operates at 18MPa working pressure. Boom lifting time is only 5.95s, and the total three-function cycle time is 10.95s, greatly shortening loading cycle duration. The machine is equipped with a distinctive automatic bucket levelling function, eliminating frequent manual adjustment and greatly improving continuous operation efficiency. Maximum dump height 3370mm and maximum dump reach 1264mm, perfectly matching mainstream medium-sized dump trucks. The 265L large-capacity fuel tank supports all-day nonstop construction.

Heavy-Duty Reinforced Drive Axles, Impact-Resistant Stable Chassis

Drive axles adopt spiral bevel gear primary reduction plus one-stage planetary wheel-side reduction structure, featuring outstanding impact resistance to withstand frequent loading shocks. Optimized vehicle gravity layout reduces body tilt during full-load transportation for stable driving. All transmission components pass strict durability tests to minimize downtime and maintenance costs. The gearbox is designed with 2 forward gears and 1 reverse gear for simple and intuitive operation, friendly for new operators.

Dual Brake System for Comprehensive Operation Safety

It adopts dual braking configuration: air-over-hydraulic four-wheel disc service brake plus manual disc parking brake. Standard front tire pressure: 0.4MPa, rear tire pressure:0.35MPa for scientifically distributed load. Responsive service brake and reliable parking lock avoid vehicle sliding on slopes, protecting operators and equipment during long-hour loading and mountain construction.

Application Scenarios

Aggregate yard loading, open-pit mining auxiliary work, highway & municipal infrastructure, concrete batching plant feeding, port material transfer, earthworks, bulk material transportation on farms.

Technical Specifications
